WaveDrom
summary
A small toolchain that turns a JSON->SVG timing diagram description into images and register/field diagrams, with an online editor that gives a 300 ms live preview. Exports include embedded SVGs, a CLI that reads JSON and writes SVG, a browser plugin that renders WaveDrom on GitHub, and a Lambda-style HTTP endpoint that returns images for blogs or specs. Integrations include Jupyter and Observable; people use it to generate testbenches, patterns and assertions. It is not a waveform viewer.
