Scene Graph: A Different Approach to Graphics in Qt
summary
A small scene graph replaces QPainter/GraphicsView for QML and renders with OpenGL ES 2.0, reorders draw calls to cut redundant state changes and avoids overdraw (example shows about 20% less wasted pixels). It uses per-effect FBOs (demo uses 16 FBOs), nested subgraphs, stencil clipping and a vertex/fragment ShaderEffectItem with automatic uniform binding. Demos run on an old Mac at ~15% CPU, gradients on N900 use textured approach to save ~5 ms, and the prototype works as advertised.
AI-written summary · about
chapters (12)
- 0:00Introduction to Qt Graphics
- 2:08Current Graphics Stack
- 5:50Limitations of Painters
- 10:43Optimizing Overdraw
- 13:16State Changes and Ordering
- 17:08Qt Scene Graph Project
- 21:11Scene Graph Structure
- 24:27Adaptation and Effects
- 26:59QML Shader Demonstration
- 33:38Nested Rendering Techniques
- 38:34Q&A: Widgets and Performance
- 47:23Q&A: Threading and APIs
