FlowBlaze: Stateful Packet Processing in Hardware

on YouTube ↗26m

" summary

FlowBlaze is an open abstraction for programming stateful packet processing on programmable NICs and FPGAs using Extended Finite State Machines with explicit per-flow state. It targets high-performance hardware (NetFPGA SmartNIC) and emphasizes flow-level parallelism to support hundreds of thousands of per-flow states at line rates (40 Gb/s), low microsecond latency, and modest power use, with both hardware and software implementations available.

AI-written summary · about

" chapters (14)

1. 0:00Start
2. 2:12Making programming easier
3. 3:05Match-Action Abstraction Limitations
4. 3:57Extending Match-Action abstractions
5. 4:12Match-Action vs Finite State Machine (FSM)
6. 5:16Multiple state machines?
7. 6:38Introducing per-flow state
8. 7:57Handling variable insertion time
9. 8:46Flow context insertion handling
10. 10:09Implementation issues
11. 10:28Avoiding race conditions
12. 12:22Does it work?
13. 14:27Stress test
14. 17:32Conclusion
