From interactive to automatic CAD data prep
summary
PiXYZ demonstrates an end-to-end CAD pipeline: import thousands of CATIA files, reduce ~3,000 parts to about half through repair and consolidation, tessellate into 4 million triangles, fix orientations with a “smart orientation” camera script, assign Unity Automotive materials, and export optimized assets (FBX/glTF/USDZ or PiXYZ format). Automation uses the embedded Python API and PiXYZ Batch to run recipes at scale and PiXYZ Connect to generate on‑demand Unity apps; runtime import is available for Windows.
AI-written summary · about
chapters (30)
- 0:00Introduction
- 0:54What is Pixie
- 2:01Partnership with Unity
- 2:49Use cases
- 3:11Portfolio
- 3:39Camel Models
- 5:56Pyxis
- 7:40Real Use Case
- 7:57Plugin Overview
- 10:31Unity Power
- 10:53Unity Power at runtime
- 11:34Studio Pixie Studio
- 12:36Staging Studio
- 13:07Data Optimization
- 13:44Creating Meshes
- 14:09Smart Orientation
- 15:02Material Assignment
- 15:35UV Texture coordinates
- 15:55Yarra Key
- 16:37Why export as Pyxis
- 17:03Full car model
- 17:15Main algorithms
- 18:42Automation
- 19:12Lexus model
- 19:41Internal solver
- 20:26Batch processing
- 21:11Automatic execution
- 21:31Light Shadows
- 21:50Toyota
- 28:19Demos
