Writing Your Own Gadget with Zephyr OS

on YouTube ↗38m

" summary

Shows how to make Zephyr OS–based embedded boards present as USB gadgets to a host PC, with concrete examples: exposing Zephyr-hosted IEEE 802.15.4 and Bluetooth radios to Linux as radio adapters, and presenting a Zephyr SoC as a USB Ethernet controller using ECM or RNDIS to act as an IP bridge. Covers related OS-side driver approaches — a custom Linux driver for IEEE 802.15.4 over USB, using standard OS drivers for USB classes like Bluetooth, and supplying Windows USB descriptors for RNDIS — and briefly touches on WebUSB for browser-based board access.

AI-written summary · about

" chapters (31)

1. 0:00Intro
2. 0:20Contents
3. 1:33Introduction: Problem
4. 1:55Introduction: Solution
5. 2:23Introduction: Zephyr
6. 2:52Hello world in Zephyr
7. 3:22USB: General overview
8. 4:25Programming USB gadgets: Standard Classes
9. 5:48Supported Standard USB Classes in Zephyr
10. 7:02Ethernet over USB: Use case
11. 8:17Ethernet over USB: Standards
12. 9:22Ethemet over USB: Enabling in Zephyr
13. 10:32Ethernet over USB: Zero configuration
14. 11:56Ethernet over USB: HTTP server app
15. 13:43Ethernet over USB: border router app
16. 14:36Ethernet over USB: Host OS Drivers
17. 15:16Ethernet over USB: Windows drivers
18. 16:25OS Drivers for Zephyr USB: OS Descriptors
19. 18:32Programming USB gadgets: Custom Classes
20. 21:05IEEE802.15.4 USB: Use case
21. 21:57IEEE802.15.4 USB gadget: Idea
22. 22:49IEEE802.15.4 USB gadget: API
23. 23:35IEEE802.15.4 USB gadget: Zephyr application
24. 24:59IEEE802.15.4 USB: Linux driver
25. 25:47WebUSB: Use case
26. 27:01WebUSB: API & Zephyr support
27. 28:09Using virtual USB controller over USB/IP
28. 30:35Zephyr Virtual USB Controller. Attaching
29. 31:51Zephyr Virtual USB Controller: Linux logs
30. 32:22Summary
31. 36:16References
