Sharing Reset GPIOs in the Linux Kernel
summary
Shared reset GPIOs cause drivers to accidentally toggle each other because GPIOs lack enable counting and probing is asynchronous. The kernel adds a concrete fix: since Linux 6.9 a reset controller can be instantiated for GPIO reset lines so drivers call Reset controller framework instead of raw gpiolib, and two drivers already use it; it handles shared asserts but not varied reset pulses. Other practical options shown are using the regulator path or a GPIO aggregator and adding enable counting for ownership.
AI-written summary · about
chapters (8)
- 0:00Shared reset GPIOs problem
- 1:03Sharing reset GPIOs issues
- 4:13Kernel limitations for shared GPIOs
- 6:39Non-exclusive GPIOs not a solution
- 8:06Reset controller for shared resets
- 10:12Reset pulses handling
- 11:39Alternative solutions like GPIO aggregator
- 13:47Unresolved problems and future work
